HCS-WCC1

Thương hiệu: HONEYWELL

Loại: VIDEO SWITCHER

96,394,000₫

4x1 VIDEO SWITCHER WITH TRACKING FUNCTION

- Built-in 4 in 1 out HDMI video signal auto switch matrix

- Communication support RS232 central control, it also has two-way transceiver code function for perfect coordination with central control system.

- Single main unit can support multiple camera position tracing control points: 250points for Pelco-D protocol, 128points for VISCA protocol.

- Support two common high-speed dome protocols (Pelco-D Baud rate 9600, VISCA Baud rate 9600).

- Support three high-speed dome control modes: RS232, RS422 and RS485.

- Preset camera position, control interface, control protocol and full-view etc. through main unit panel buttons

Model	HCS-WCC1
Input	4 HDMI: On a female HDMI connector
Output	1 HDMI: On a female HDMI connector
High-Speed PTZ control interface	RS-232, RS-422 and RS-485
Data port	Wireless conference host communication interface
Configuration port for PC	RS-232 reserved
Bandwidth	Up to 1080p, UXGA
Switching Time Between Inputs	2 to 3 seconds
Video Latency	Less than 2 frames
Input Resolution	Upto 1920x1080@30/60Hz
Output Resolution	Upto 1920x1080p@30/60Hz
Power Supply	AC: 110 ~ 240V
Operating Temperature	<45ºC
Storage Temperature	-40 ºC to +70 ºC
Humidity	10% to 90%, non-condensing
Dimension	485 x 270 x 44(mm)
